YM-201636 is a potent and selective PIKfyve inhibitor with an IC₅₀ of 33 nM. YM-201636 also inhibits p110α with an IC₅₀ of 3.3 μM. YM-201636 inhibits retroviral replication.

Acute treatment of cells with YM-201636 shows that the PIKfyve pathway is involved in the sorting of endosomal transport, with inhibition leading to the accumulation of a late endosomal compartment and blockade of retroviral exit. The yeast orthologue of PIKfyve, Fab1, is found to be insensitive to YM-201636 (IC₅₀>5 μM). YM-201636 does not inhibit a type IIγ PtdInsP kinase even at 10 μM and inhibits a mouse type Iα PtdInsP kinase with an IC₅₀>2 μM^[1]. YM-201636 almost completely inhibits basal and insulin-activated 2-deoxyglucose uptake at doses as low as 160 nM, with IC₅₀=54 nM for the net insulin response. YM-201636 also completely inhibits insulin-dependent activation of class IA PI 3-kinase^[2]. At low doses (10-25 nM), YM-201636 inhibits preferentially PtdIns5P rather than PtdIns(3,5)P2 production, whereas at higher doses, the two products are similarly inhibited. YM-201636 at 160 nM inhibits PtdIns5P synthesis twice more effectively compared with PtdIns(3,5)P2 synthesis^[3]. MDCK cells treated with YM-201636 accumulate the tight junction protein claudin-1 intracellularly. YM-201636 treatment blocks the continuous recycling of claudin-1/claudin-2 and delays epithelial barrier formation^[4].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

467.48

C₂₅H₂₁N₇O₃

371942-69-7

Room temperature in continental US; may vary elsewhere.

Powder	-20°C	3 years
	4°C	2 years
In solvent	-80°C	6 months
	-20°C	1 month

In Vitro:

DMSO : ≥ 47 mg/mL (100.54 mM)

* “≥” means soluble, but saturation unknown.

*

请根据产品在不同溶剂中的溶解度选择合适的溶剂配制储备液；一旦配成溶液，请分装保存，避免反复冻融造成的产品失效。
储备液的保存方式和期限：-80°C, 6 months; -20°C, 1 month。-80°C 储存时，请在 6 个月内使用，-20°C 储存时，请在 1 个月内使用。

In Vivo:

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 2.5 mg/mL (5.35 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (5.35 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 2.

  请依序添加每种溶剂： 10% DMSO    90% (20% SBE-β-CD in saline)

  Solubility: 2.5 mg/mL (5.35 mM); Suspended solution; Need ultrasonic

  此方案可获得 2.5 mg/mL (5.35 mM) 的均匀悬浊液，悬浊液可用于口服和腹腔注射。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明
• 3.

  请依序添加每种溶剂： 10% DMSO    90% corn oil

  Solubility: ≥ 2.5 mg/mL (5.35 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (5.35 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL玉米油中，混合均匀。

• [1]. Jefferies HB, et al. A selective PIKfyve inhibitor blocks PtdIns(3,5)P(2) production and disrupts endomembrane transport and retroviral budding. EMBO Rep, 2008, 9(2), 164-170.

  [2]. Ikonomov OC, et al. YM-201636, an inhibitor of retroviral budding and PIKfyve-catalyzed PtdIns(3,5)P2 synthesis, halts glucose entry by insulin in adipocytes. Biochem Biophys Res Commun. 2009 May 8;382(3):566-70.

  [3]. Sbrissa D, et al. Functional dissociation between PIKfyve-synthesized PtdIns5P and PtdIns(3,5)P2 by means of the PIKfyve inhibitor YM-201636. Am J Physiol Cell Physiol. 2012 Aug 15;303(4):C436-46.

  [4]. Dukes JD, et al. The PIKfyve inhibitor YM-201636 blocks the continuous recycling of the tight junction proteins claudin-1 and claudin-2 in MDCK cells. PLoS One. 2012;7(3):e28659.

  [5]. Ikonomov OC, et al. YM201636, an inhibitor of retroviral budding and PIKfyve-catalyzed PtdIns(3,5)P2 synthesis, halts glucose entry by insulin in adipocytes. Biochem Biophys Res Commun. 2009 May 8;382(3):566-70.

Following 3T3L1 adipocyte serum-starvation and insulin stimulation, cell lysates containing protease inhibitors are clarified and then subjected to immunoprecipitation with anti-PIKfyve antibodies. Washed beads are mixed with 100 μM PtdIns and preincubated for 15 min with YM-201636 (100 nM) or vehicle in the assay buffer (50 mM Tris-HCl, pH 7.5, 1 mM EGTA and 10 mM MgCl2). The kinase assay (50 μL final volume) is carried out for 15 min at 37 °C with 15 μM ATP and [γ-³²P]ATP (30 μCi). Lipids are extracted, spotted on TLC glass plates (250 μm), resolved by a chloroform/methanol/water/ammonia solvent system and detected by autoradiography^[2].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

YM-201636 is dissolved in DMSO and diluted with DMEM and added to cells at a final concentration of 800 nM. Cells are treated with YM-201636 or a DMSO control for 2 h. For TER measurements cells are plated at confluency on Transwell permeable polyester filters (0.4 µm pore size) with surface area of 0.33 cm². Media is changed ever 2-3 days and cells are grown for 7 days prior to TER measurements^[4].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

• [1]. Jefferies HB, et al. A selective PIKfyve inhibitor blocks PtdIns(3,5)P(2) production and disrupts endomembrane transport and retroviral budding. EMBO Rep, 2008, 9(2), 164-170.

  [2]. Ikonomov OC, et al. YM-201636, an inhibitor of retroviral budding and PIKfyve-catalyzed PtdIns(3,5)P2 synthesis, halts glucose entry by insulin in adipocytes. Biochem Biophys Res Commun. 2009 May 8;382(3):566-70.

  [3]. Sbrissa D, et al. Functional dissociation between PIKfyve-synthesized PtdIns5P and PtdIns(3,5)P2 by means of the PIKfyve inhibitor YM-201636. Am J Physiol Cell Physiol. 2012 Aug 15;303(4):C436-46.

  [4]. Dukes JD, et al. The PIKfyve inhibitor YM-201636 blocks the continuous recycling of the tight junction proteins claudin-1 and claudin-2 in MDCK cells. PLoS One. 2012;7(3):e28659.

  [5]. Ikonomov OC, et al. YM201636, an inhibitor of retroviral budding and PIKfyve-catalyzed PtdIns(3,5)P2 synthesis, halts glucose entry by insulin in adipocytes. Biochem Biophys Res Commun. 2009 May 8;382(3):566-70.
