Monomethyl auristatin E (MMAE; SGD-1010) is a synthetic derivative of dolastatin 10 and functions as a potent mitotic inhibitor by inhibiting tubulin polymerization. MMAE is widely used as a cytotoxic component of antibody-drug conjugates (ADCs) to treat several different cancer types.

Monomethyl auristatin E (MMAE) is efficiently released from SGN-35 within CD30⁺ cancer cells and, due to its membrane permeability, is able to exert cytotoxic activity on bystander cells^[1]. MMAE sensitizes colorectal and pancreatic cancer cells to IR in a schedule and dose dependent manner correlating with mitotic arrest. Radiosensitization is evidenced by decreased clonogenic survival and increased DNA double strand breaks in irradiated cells^[2].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

Monomethyl auristatin E (MMAE) in combination with IR results in tumor growth delay, tumor-targeted ACPP-cRGD-MMAE with IR produces a more robust and significantly prolongs tumor regression in xenograft models^[2].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

717.98

C₃₉H₆₇N₅O₇

474645-27-7

Room temperature in continental US; may vary elsewhere.

4°C, stored under nitrogen

*该产品在溶液状态不稳定，建议您现用现配，即刻使用。

Ethanol : 50 mg/mL (69.64 mM; Need ultrasonic)

DMSO : ≥ 48 mg/mL (66.85 mM)

* “≥” means soluble, but saturation unknown.

请根据产品在不同溶剂中的溶解度，选择合适的溶剂配制储备液；该产品在溶液状态不稳定，建议您现用现配，即刻使用。

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： 5% DMSO    40% PEG300    5% Tween-80    50% saline

  Solubility: 2.62 mg/mL (3.65 mM); Clear solution; Need ultrasonic
• 2.

  请依序添加每种溶剂： 5% DMSO    95% (20% SBE-β-CD in saline)

  Solubility: ≥ 2.62 mg/mL (3.65 mM); Clear solution
• 3.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 2.5 mg/mL (3.48 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.48 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 4.

  请依序添加每种溶剂： 10% DMSO    90% (20% SBE-β-CD in saline)

  Solubility: ≥ 2.5 mg/mL (3.48 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.48 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明
• 5.

  请依序添加每种溶剂： 10% DMSO    90% corn oil

  Solubility: ≥ 2.5 mg/mL (3.48 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.48 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL玉米油中，混合均匀。

• 6.

  请依序添加每种溶剂： 10% EtOH    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 2.5 mg/mL (3.48 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.48 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 EtOH 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 7.

  请依序添加每种溶剂： 10% EtOH    90% (20% SBE-β-CD in saline)

  Solubility: ≥ 2.5 mg/mL (3.48 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.48 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 EtOH 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明
• 8.

  请依序添加每种溶剂： 10% EtOH    90% corn oil

  Solubility: ≥ 2.5 mg/mL (3.48 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.48 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 EtOH 储备液加到 900 μL玉米油中，混合均匀。

• 9.

  请依序添加每种溶剂： 1% DMSO    99% saline

  Solubility: ≥ 0.52 mg/mL (0.72 mM); Clear solution

• [1]. Okeley, et al. Intracellular Activation of SGN-35, a Potent Anti-CD30 Antibody-Drug Conjugate. Clinical Cancer Research (2010), 16(3), 888-897.

  [2]. Lisa Buckel, et al. Tumor radiosensitization by monomethyl auristatin E: mechanism of action and targeted delivery. Cancer Res. 2015 Apr 1;75(7):1376-87.

Monomethyl auristatin E (MMAE, 5 nM) and ionizing radiation (IR) treated cells are harvested and lysed in RIPA buffer with protease and phosphatase inhibitors. Thirty μg of lysate undergo electrophoresis using 4-12% Bis-Tris gels, transferred to PVDF membranes and incubated with indicated primary antibodies. Blots are developed by ECL.

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

Mice^[2]
6-8 week old female athymic nu/nu mice are injected subcutaneously into thighs with 5×10⁶ HCT-116 or PANC-1 cells in a 1:1 Matrigel and PBS solution. Mice are treated with IR or intravenous (IV) injection of ACPP-cRGD-MMAE (6 nmoles/day, 18 nmoles total, i.v.), tumor tissue is harvested, formalin fixed and paraffin embedded followed by staining with indicated antibodies. The primary antibody is used at a 1:250 dilution and is visualized using DAB as a chromagen with the UltraMap system.

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.
