MMAF-Ome, an antitubulin agent, is also an ADC cytotoxin. MMAF-Ome inhibits several tumor cell lines with IC₅₀s of 0.056 nM, 0.166 nM, 0.183 nM, and 0.449 nM for MDAMB435/5T4, MDAMB361DYT2, MDAMB468, and Raji (5T4^–) cell lines, respectively.

2.5F-Fc and 2.5F-Fc-MMAF have similar IC₅₀ values (6.9±1.1 vs. 8.3±1.3 nM, respectively), indicating that MMAF conjugation has negligible impact on integrin-binding affinity^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

745.99

C₄₀H₆₇N₅O₈

863971-12-4

Room temperature in continental US; may vary elsewhere.

Powder	-20°C	3 years
	4°C	2 years

*该产品在溶液状态不稳定，建议您现用现配，即刻使用。

In Vitro:

DMSO : ≥ 100 mg/mL (134.05 mM)

* “≥” means soluble, but saturation unknown.

*

请根据产品在不同溶剂中的溶解度，选择合适的溶剂配制储备液；该产品在溶液状态不稳定，建议您现用现配，即刻使用。

In Vivo:

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 2.5 mg/mL (3.35 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.35 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 2.

  请依序添加每种溶剂： 10% DMSO    90% (20% SBE-β-CD in saline)

  Solubility: ≥ 2.5 mg/mL (3.35 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.35 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明
• 3.

  请依序添加每种溶剂： 10% DMSO    90% corn oil

  Solubility: ≥ 2.5 mg/mL (3.35 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (3.35 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL玉米油中，混合均匀。

• [1]. Currier NV, et al. Targeted Drug Delivery with an Integrin-Binding Knottin-Fc-MMAF Conjugate Produced by Cell-Free Protein Synthesis. Mol Cancer Ther. 2016 Jun;15(6):1291-300

Cells are seeded in a 96-well plate at a density of 2,000 cells per well and grown overnight at 37°C, 5% CO₂ in the media described for each cell line above. Cells are subsequently treated with 100 μL of fresh media, containing varying concentrations of knottin-Fc fusion proteins or linker-modified MMAF, and incubated for 5 days at 37°C, 5% CO₂. Cell proliferation is measured using the Cell Counting Kit-8 (CCK-8), by adding the water-soluble tetrazolium salt, WST-8, to each well in an amount equal to 10% of the culture volume. After incubation for 1 hour at 37°C, absorbance at 450 nm is measured with a Synergy H4 microtiter plate reader. Cell proliferation is expressed as a percentage of absorbance relative to the control of untreated cells. Percent maximum proliferation is then reported as (sample − background)/(control − background) × 100. Error bars represent the SD of experiments performed in triplicate.

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

• [1]. Currier NV, et al. Targeted Drug Delivery with an Integrin-Binding Knottin-Fc-MMAF Conjugate Produced by Cell-Free Protein Synthesis. Mol Cancer Ther. 2016 Jun;15(6):1291-300
