PGMI-004A is a potent phosphoglycerate mutase 1 (PGAM1) inhibitor with an IC₅₀ of 13.1 μM.

IC50: 13.1 μM (PGAM1)^[1]

PGMI-004A inhibits PGAM1 with an IC₅₀ of approximately 13.1 μM and the K_d value of the PGMI-004A-PGAM1 interaction is determined to be 7.2±0.7 μM from fluorescence-based binding assay. PGMI-004A may allosterically modulate the enzyme activity of PGAM1. The K_i value is determined to be 3.91±2.50 μM using Dixon plot analysis. The K_d value for protein-ligand interaction is calculated to be 9.4±2.0 μM. Inhibition of PGAM1 activity by PGMI-004A (20 μM) treatment results in decreased 2-PG and increased 3-PG levels in H1299 cells, which could be rescued by treatment with methyl-2-PG. Treatment with PGMI-004A (20 μM) results in significantly reduced lactate production that is rescued by methyl-2-PG treatment, but has no significant effect on intracellular ATP levels. PGMI-004A (20 μM) treatment results in decreased oxidative PPP flux and NADPH/NADP+ratio, as well as reduced biosynthesis of lipids and RNA, and cell proliferation in H1299 cells. PGMI-004A treatment results in decreased cell proliferation of diverse human cancer and leukemia cells, but not control human dermal fibroblasts (HDF), human foreskin fibroblasts (HFF), human HaCaT keratinocyte cells and human melanocyte PIG1 cells, suggesting minimal non-specific toxicity of PGMI-004A in normal, proliferating human cells^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

The xenograft experiment is performed by injecting H1299 cells to nude mice. Six days post-injection, mice are divided into two groups (n=8/group) and treated with either PGMI-004A (100mg/kg/day) or vehicle for 21 days. PGMI-004A treatment results in significantly decreased tumor growth and tumor size in treated mice compared with mice receiving vehicle control. Moreover, treatment with PGMI-004A effectively inhibits PGAM1 enzyme activity in tumors in vivo in resected tumors from xenograft nude mice^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

463.38

C₂₁H₁₂F₃NO₆S

1313738-90-7

Room temperature in continental US; may vary elsewhere.

Powder	-20°C	3 years
	4°C	2 years
In solvent	-80°C	6 months
	-20°C	1 month

In Vitro:

DMSO : ≥ 125 mg/mL (269.76 mM)

* “≥” means soluble, but saturation unknown.

*

请根据产品在不同溶剂中的溶解度选择合适的溶剂配制储备液；一旦配成溶液，请分装保存，避免反复冻融造成的产品失效。
储备液的保存方式和期限：-80°C, 6 months; -20°C, 1 month。-80°C 储存时，请在 6 个月内使用，-20°C 储存时，请在 1 个月内使用。

In Vivo:

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 2.08 mg/mL (4.49 mM); Clear solution

  此方案可获得 ≥ 2.08 mg/mL (4.49 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 20.8 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 2.

  请依序添加每种溶剂： 10% DMSO    90% (20% SBE-β-CD in saline)

  Solubility: ≥ 2.08 mg/mL (4.49 mM); Clear solution

  此方案可获得 ≥ 2.08 mg/mL (4.49 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 20.8 mg/mL 的澄清 DMSO 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明

• [1]. Hitosugi T, et al. Phosphoglycerate mutase 1 coordinates glycolysis and biosynthesis to promote tumor growth. Cancer Cell. 2012 Nov 13;22(5):585-600.

For adherent cell viability assay such as H1299 cells with trypan blue exclusion, 5×10⁴ cells are seeded in 6-well plate 24 h before the assay starts and are cultured at 37°C. 24 h after seeding, cells are treated with PGMI-004A (5, 10, 20, and 40 μM) and incubated at 37°C for indicated times. Cell viability is determined by counting drug-treated cells compared to DMSO-treated control cells with trypan blue exclusion under a microscope (×40). For MTT cell viability assay of adherent cells, 5×10³ cells are seeded in 96-well plate 24 h before the assay starts and are cultured at 37°C. 24 h after seeding, cells are treated with PGMI-004A and incubated at 37°C for 3 days. Cell viability is determined by using CellTiter96Aqueous One solution proliferation kit^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

Mice^[1]
Nude mice (female 6-8-week-old) are subcutaneously injected with 10×10⁶ H1299 cells harboring empty vector on the left flank, and cells with stable knockdown of endogenous hPGAM1 on the right flank, respectively. The tumors are harvested and weighed at the experimental endpoint, and the masses of tumors (g) derived from cells with and without stable knockdown of endogenous hPGAM1 in both flanks of each mouse are compared. Statistical analyses are performed by comparison in relation to the control group with a two-tailed paired Student’s ttest. For drug evaluation of PGMI-004A using xenograft mice, PGMI-004A is administered by daily i.p. injection at a dose of 100 mg/kg from 6 days after subcutaneous injection of H1299 cells on right flank of each mouse. Tumor growth is recorded by measurement of two perpendicular diameters of the tumors over a 3-week course^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

• [1]. Hitosugi T, et al. Phosphoglycerate mutase 1 coordinates glycolysis and biosynthesis to promote tumor growth. Cancer Cell. 2012 Nov 13;22(5):585-600.
