PX-478 is an orally active HIF-1α inhibitor with potent antitumor activities. PX-478 can cross the blood-brain barrier^[1][2].

HIF-1α^[1]

PC3 and DU 145 cells express HIF-1α protein are treated with PX-478 for 20 hr under normoxia. PC3 cells are more sensitive to PX-478 as compared with DU 145 cells. Densitometric analysis shows that the IC₅₀ for HIF-1α inhibition for PC3 cells under normoxic condition is 20-25 μM, whereas the IC₅₀ for HIF-1α inhibition for the DU 145 cells is 40-50 μM. PC3 and DU 145 cells are treated with different concentrations of PX-478 (10, 20, 30, 40, 50, and 60 μM) for 18-20 hr under normoxia or hypoxia. Under normoxia, PC3 cells are more sensitive to PX-478 than DU 145 cells. IC₅₀ for clonogenic survival (n=3) is 17 μM for PC3 cells and 35 μM for DU 145 cells. When cells are treated with the drug under hypoxic condition for 18 hr, the IC₅₀ is 16 μM for PC3 cells and 22 μM for DU 145 cells. Thus DU 145 cells are more sensitive to PX-478 under hypoxic condition^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

PX-478 is administered to mice with congenital HO (Nfatc1-Cre/caACVR1^fl/fl) every other day starting from birth for 2 wk. Treated mice have significantly less ectopic bone at the ankle joints compared with mutant mice treated with vehicle (6.8 mm³ vs. 2.2 mm³, P<0.01)^[2].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

394.12

C₁₃H₂₀Cl₄N₂O₃

685898-44-6

Room temperature in continental US; may vary elsewhere.

-20°C, stored under nitrogen, away from moisture

*In solvent : -80°C, 6 months; -20°C, 1 month (stored under nitrogen, away from moisture)

DMSO : 100 mg/mL (253.73 mM; Need ultrasonic)

H₂O : ≥ 35 mg/mL (88.81 mM)

* “≥” means soluble, but saturation unknown.

请根据产品在不同溶剂中的溶解度选择合适的溶剂配制储备液；一旦配成溶液，请分装保存，避免反复冻融造成的产品失效。
储备液的保存方式和期限：-80°C, 6 months; -20°C, 1 month (stored under nitrogen, away from moisture)。-80°C 储存时，请在 6 个月内使用，-20°C 储存时，请在 1 个月内使用。

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： Saline

  Solubility: 16.67 mg/mL (42.30 mM); Clear solution; Need ultrasonic
• 2.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 5 mg/mL (12.69 mM); Clear solution

  此方案可获得 ≥ 5 mg/mL (12.69 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 50.0 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 3.

  请依序添加每种溶剂： 10% DMSO    90% (20% SBE-β-CD in saline)

  Solubility: ≥ 5 mg/mL (12.69 mM); Clear solution

  此方案可获得 ≥ 5 mg/mL (12.69 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 50.0 mg/mL 的澄清 DMSO 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明
• 4.

  请依序添加每种溶剂： 10% DMSO    90% corn oil

  Solubility: ≥ 5 mg/mL (12.69 mM); Clear solution

  此方案可获得 ≥ 5 mg/mL (12.69 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 50.0 mg/mL 的澄清 DMSO 储备液加到 900 μL玉米油中，混合均匀。

• 5.

  请依序添加每种溶剂： 5% DMSO    40% PEG300    5% Tween-80    50% saline

  Solubility: ≥ 2.5 mg/mL (6.34 mM); Clear solution
• 6.

  请依序添加每种溶剂： 5% DMSO    95% (20% SBE-β-CD in saline)

  Solubility: ≥ 2.5 mg/mL (6.34 mM); Clear solution
• 7.

  请依序添加每种溶剂： 1% DMSO    99% saline

  Solubility: ≥ 0.5 mg/mL (1.27 mM); Clear solution

• [1]. Palayoor ST, et al. PX-478, an inhibitor of hypoxia-inducible factor-1alpha, enhances radiosensitivity of prostate carcinoma cells. Int J Cancer. 2008 Nov 15;123(10):2430-2437.

  [2]. Agarwal S, et al. Inhibition of Hif1α prevents both trauma-induced and genetic heterotopic ossification. Proc Natl Acad Sci U S A. 2016 Jan 19;113(3):E338-47.

To determine the effect of PX-478 in combination with radiation, cells are treated with PX-478 for 24 hr under normoxic condition, irradiated and plated after 1 hr. Colonies are stained with crystal violet after 12 days and the colonies of >50 cells are counted. For combination treatments, net survival is calculated by correcting the toxicity of PX-478 alone. Enhancement factor (EF) is calculated by dividing the dose of radiation required to reduce plating efficiency to 10% when cells are treated with radiation alone by the dose of radiation required to reduce plating efficiency to 10% when cells are treated with PX-478 and radiation^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

Mice^[2]
Burn/tenotomy or hybrid HO mice are administered PX-478 (100 mg/kg) or Rapamycin (5 mg/kg) in PBS solution via intraperitoneal injection. Mice receive injections every other day for the duration of the study. Nfatc1-Cre/caACVR1^fl/wt mice are administered PX-478 (100 mg/kg) every other day for a total of 2 wk.

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

• [1]. Palayoor ST, et al. PX-478, an inhibitor of hypoxia-inducible factor-1alpha, enhances radiosensitivity of prostate carcinoma cells. Int J Cancer. 2008 Nov 15;123(10):2430-2437.

  [2]. Agarwal S, et al. Inhibition of Hif1α prevents both trauma-induced and genetic heterotopic ossification. Proc Natl Acad Sci U S A. 2016 Jan 19;113(3):E338-47.
