SR9009 is a REV-ERBα/β agonist with IC₅₀s of 670 nM and 800 nM for REV-ERBα and REV-ERBβ, respectively.

IC50: 670 nM (Rev-ErbBα), 800 nM (Rev-ErbBβ)^[1]

SR9009 dose-dependently increases the REV-ERB-dependent repressor activity assessed in HEK293 cells expressing a chimeric Gal4 DNA Binding Domain (DBD)-REV-ERB ligand binding domain (LBD)α or β and a Gal4-responsive luciferase reporter (SR9009: REV-ERBα IC₅₀=670 nM, REV-ERBβ IC₅₀=800 nM). SR9009 potently and efficaciously suppresses transcription in a cotransfection assay using full-length REV-ERBα along with a luciferase reporter driven by the Bmal1 promoter (IC₅₀=710 nM). SR9009 suppresses the expression of BMAL1 mRNA in HepG2 cells in a REV-ERBα/β-dependent manner. Direct binding of the SR9009 to REV-ERBα is also confirmed using circular dichrosim analysis (K_d=800 nM)^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

While the stress of handling and twice-daily injections caused weight loss in vehicle-treated controls, weight loss of SR9009-treated animals is 60% greater. SR9009 (100 mg/kg ,i.p.) treated mice exhibit a more severe reduction in adiposity. Plasma non-esterified fatty acids (NEFA) are also reduced (23%) along with plasma glucose (19%) in the SR9009 treated animals. In the white adipose tissue (WAT) , SR9009 treatment results in a decrease in expression of genes encoding enzymes involved in triglyceride (TG) synthesis as is also observed in lean mice^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

437.94

C₂₀H₂₄ClN₃O₄S

1379686-30-2

Room temperature in continental US; may vary elsewhere.

DMSO : ≥ 100 mg/mL (228.34 mM)

* “≥” means soluble, but saturation unknown.

请根据产品在不同溶剂中的溶解度选择合适的溶剂配制储备液；一旦配成溶液，请分装保存，避免反复冻融造成的产品失效。
储备液的保存方式和期限：-80°C, 6 months; -20°C, 1 month。-80°C 储存时，请在 6 个月内使用，-20°C 储存时，请在 1 个月内使用。

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： 6% DMSO    10% Cremophor EL    84% ddH2O

  Solubility: 20 mg/mL (45.67 mM); Suspended solution; Need ultrasonic
• 2.

  请依序添加每种溶剂： 5% DMSO    40% PEG300    5% Tween-80    50% saline

  Solubility: 2.5 mg/mL (5.71 mM); Suspended solution; Need ultrasonic
• 3.

  请依序添加每种溶剂： 5% DMSO    95% (20% SBE-β-CD in saline)

  Solubility: 2.5 mg/mL (5.71 mM); Suspended solution; Need ultrasonic
• 4.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: 2.08 mg/mL (4.75 mM); Suspended solution; Need ultrasonic

  此方案可获得 2.08 mg/mL (4.75 mM) 的均匀悬浊液，悬浊液可用于口服和腹腔注射。

  以 1 mL 工作液为例，取 100 μL 20.8 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 5.

  请依序添加每种溶剂： 10% DMSO    90% (20% SBE-β-CD in saline)

  Solubility: 2.08 mg/mL (4.75 mM); Suspended solution; Need ultrasonic

  此方案可获得 2.08 mg/mL (4.75 mM) 的均匀悬浊液，悬浊液可用于口服和腹腔注射。

  以 1 mL 工作液为例，取 100 μL 20.8 mg/mL 的澄清 DMSO 储备液加到 900 μL 20% 的 SBE-β-CD 生理盐水水溶液中，混合均匀。

  将 2 g 磺丁基醚 β-环糊精加入 5 mL 生理盐水中，再用生理盐水定容至 10 mL，完全溶解，澄清透明
• 6.

  请依序添加每种溶剂： 10% DMSO    90% corn oil

  Solubility: ≥ 2.08 mg/mL (4.75 mM); Clear solution

  此方案可获得 ≥ 2.08 mg/mL (4.75 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 20.8 mg/mL 的澄清 DMSO 储备液加到 900 μL玉米油中，混合均匀。

• [1]. Solt LA, et al. Regulation of circadian behaviour and metabolism by synthetic REV-ERB agonists. Nature. 2012 Mar 29;485(7396):62-68.

HEK293 cells are grown in 96-well plates (1×10⁶/well) and are transiently transfected using Lipofectamine. Cells are transfected with a total of 200 ng of DNA per well consisting of the pGL4 mIL-17 firefly luciferase reporter construct, the pGL4 mIL-17 + CNS-5 firefly luciferase reporter construct, or the pGL4 mIL-17 2kB RORE mutant (100 ng/well) , an actin promoter Renilla reniformis luciferase reporter (50 ng/well), and either control vector alone or the test DNA (full-length RORα or full-length RORγ at 50 ng/well). All 48 human nuclear receptors are represented in the specificity assay and SR9009 is tested at a concentration of 20 μM. The format of the assay is a cotransfection assay with Gal4 DNA binding domain-nuclear receptor fusions in HEK293 cells^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

Mice^[1]
For circadian gene expression experiments male C57BL6 mice (8-10 weeks of age) are either maintained on a L:D (12h:12h) cycle or on constant darkness. At circadian time (CT) 0 animals are administered a single dose of 100 mg/kg SR9009 or SR9011 (i.p.) and groups of animals (n=6) are sacrificed at CT0, CT6, CT12 and CT18. Gene expression is determined by real time QPCR.

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

• [1]. Solt LA, et al. Regulation of circadian behaviour and metabolism by synthetic REV-ERB agonists. Nature. 2012 Mar 29;485(7396):62-68.

SR9011 is a REV-ERBα/β agonist with IC₅₀s of 790 nM and 560 nM for REV-ERBα and REV-ERBβ, respectively.

IC50: 790 nM (Rev-ErbBα), 560 nM (Rev-ErbBβ)^[1]

SR9011 dose-dependently increases the REV-ERB-dependent repressor activity assessed in HEK293 cells expressing a chimeric Gal4 DNA Binding Domain (DBD) – REV-ERB ligand binding domain (LBD) α or β and a Gal4-responsive luciferase reporter (REV-ERBα IC₅₀=790 nM, REV-ERBβ IC₅₀=560 nM). SR9011 potently and efficaciously suppresses transcription in a cotransfection assay using full-length REV-ERBα along with a luciferase reporter driven by the Bmal1 promoter (SR9011 IC₅₀=620 nM). SR9011 suppresses the expression ofBMAL1 mRNA in HepG2 cells in a REV-ERBα/β-dependent manner^[1] SR9011 suppresses proliferation of the breast cancer cell lines regardless of their ER or HER2 status. SR9011 appears to pause the cell cycle of the breast cancer cells prior to M phase. Cyclin A (CCNA2) is identified as a direct target gene of REV-ERB suggesting that suppression of expression of this cyclin by SR9011 may mediate the cell cycle arrest. Treatment with SR9011 results in an increase in cells in the G₀/G₁ phase and a decrease of cells in S and G₂/M phase suggesting that activation of REV-ERB may be resulting in decreased transition from G₁ to S phase and/or from S to G₂/M phase^[2].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

SR9011 displays reasonable plasma exposure, thus, the expression of REV-ERB responsive genes is examined in the liver of mice treated with various doses of SR9011 for 6-days. The plasminogen activator inhibitor type 1 gene (Serpine1) is a REV-ERB target gene and displays dose-dependent suppression of expression in response to SR9011. The cholesterol 7α-hydroxylase (Cyp7a1) and sterol response element binding protein (Srepf1) genes have also been shown to be responsive to REV-ERB and are dose-dependently suppressed with increasing amounts of SR9011. After 12 days in D:D conditions mice are injected with a single dose of SR9011 or vehicle at CT6 (peak expression of Rev-erbα). Vehicle injection causes no disruption in circadian locomotor activity. However, administration of a single dose of SR9011 results in loss of locomotor activity during the subject dark phase. Normal activity returns the next circadian cycle, consistent with clearance of the drugs in less than 24h. The SR9011-dependent decrease in wheel running behavior in the mice under constant darkness conditions is dose-dependent and that the potency (ED₅₀=56 mg/kg) is similar to the potency of SR9011-mediated suppression of a REV-ERB responsive gene, Srebf1 , in vivo (ED₅₀=67mg/kg)^[1].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

479.04

C₂₃H₃₁ClN₄O₃S

1379686-29-9

Room temperature in continental US; may vary elsewhere.

DMSO : ≥ 43 mg/mL (89.76 mM)

* “≥” means soluble, but saturation unknown.

请根据产品在不同溶剂中的溶解度选择合适的溶剂配制储备液；一旦配成溶液，请分装保存，避免反复冻融造成的产品失效。
储备液的保存方式和期限：-80°C, 6 months; -20°C, 1 month。-80°C 储存时，请在 6 个月内使用，-20°C 储存时，请在 1 个月内使用。

请根据您的实验动物和给药方式选择适当的溶解方案。以下溶解方案都请先按照 In Vitro 方式配制澄清的储备液，再依次添加助溶剂：

——为保证实验结果的可靠性，澄清的储备液可以根据储存条件，适当保存；体内实验的工作液，建议您现用现配，当天使用； 以下溶剂前显示的百
分比是指该溶剂在您配制终溶液中的体积占比；如在配制过程中出现沉淀、析出现象，可以通过加热和/或超声的方式助溶

• 1.

  请依序添加每种溶剂： 10% DMSO    40% PEG300    5% Tween-80    45% saline

  Solubility: ≥ 2.5 mg/mL (5.22 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (5.22 mM，饱和度未知) 的澄清溶液。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀；向上述体系中加入50 μL Tween-80，混合均匀；然后继续加入 450 μL生理盐水定容至 1 mL。

  将 0.9 g 氯化钠，完全溶解于 100 mL ddH₂O 中，得到澄清透明的生理盐水溶液

• 2.

  请依序添加每种溶剂： 10% DMSO    90% corn oil

  Solubility: ≥ 2.5 mg/mL (5.22 mM); Clear solution

  此方案可获得 ≥ 2.5 mg/mL (5.22 mM，饱和度未知) 的澄清溶液，此方案不适用于实验周期在半个月以上的实验。

  以 1 mL 工作液为例，取 100 μL 25.0 mg/mL 的澄清 DMSO 储备液加到 900 μL玉米油中，混合均匀。

• [1]. Solt LA, et al. Regulation of circadian behaviour and metabolism by synthetic REV-ERB agonists. Nature. 2012 Mar 29;485(7396):62-8.

  [2]. Wang Y, et al. Anti-proliferative actions of a synthetic REV-ERBα/β agonist in breast cancer cells. Biochem Pharmacol. 2015 Aug 15;96(4):315-22.

MCF10A, MDA-MB-231, MCF-7, MDA-MB-361, SKBR3, BT474 cells are plated in 6-well plates one day before treatment. The MTT cell proliferation assays are performed. Briefly, 3×10³ to 5 × 10³ cells per well are plated in 96-well plates. Twenty-four hours later, cells are treated with SR9011 (0, 2, 4, 6, 8 and 10 μM) or DMSO. Seventy-two hours after treatment, the cells are labeled with 1.2 mM MTT and incubated for 4 hours. DMSO is then added and readings are taken on a plate reader at 540 nm^[2].

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

Mice^[1]
For circadian gene expression experiments male C57BL6 mice (8-10 weeks of age) are either maintained on a L:D (12h:12h) cycle or on constant darkness. At circadian time (CT) 0 animals are administered a single dose of 100 mg/kg SR9011 (i.p.) and groups of animals (n=6) are sacrificed at CT0, CT6, CT12 and CT18. Gene expression is determined by real time QPCR.

上海金畔生物科技有限公司 has not independently confirmed the accuracy of these methods. They are for reference only.

• [1]. Solt LA, et al. Regulation of circadian behaviour and metabolism by synthetic REV-ERB agonists. Nature. 2012 Mar 29;485(7396):62-8.

  [2]. Wang Y, et al. Anti-proliferative actions of a synthetic REV-ERBα/β agonist in breast cancer cells. Biochem Pharmacol. 2015 Aug 15;96(4):315-22.
